The LoGo 10/12 is available in both transit mix, and central mix-paving configurations.

The Central mix-paving LoGo 10/12 batch plants are equipped with 10 or 12 cubic yard batcher and mixer providing a 300 cubic yards per hour capacity. Self contained, and fully equipped, central mix-paving plants include everything you need to begin production.

The LoGo 10/12 batch plants are designed for easy moves, and fast setup.

Transit mix LoGo 10/12 features:
  • Aggregate bin - 45 cu. yd., 66 ton, C.P.M.B. rated, four equal compartments
  • Aggregate batcher - 10/12 cubic yards, load cell
  • Gravity cement storage - 2120 cubic feet, 530 Bbl. C.P.M.B. rated single compartment bin, 4" cement delivery pipe, 10" butterfly gates, atmospheric vent
  • Cement batcher- 10/12 cubic yards, C.P.M.B. volume, load cell, air-operated vibrator, aeration pads, 10" butterfly gates with inching control (includes 3 horsepower aeration blower)
  • 36" batch belt, 500 feet per minute belt rate, 20 horsepower drive
  • 3" 360 gpm Badger Hot Water Meter with electric cutoff valve
  • 10 horsepower two-stage air compressor with 80 gallon tank
  • Tilt-up mixer - 10 or 12 cubic yards capacity (mixer mounted on a steel stand, provided by RexCon)
  • Mixer dump-cone for charging truck mixers (includes outboard supports)
  • One set of steel risers to elevate the plant to 13'6" steel clearance (11'6" rubber clearance under dump cone)
  • 460 volt power panel (includes NEMA starters for batch belt, air compressor, aeration blower and tilt-mixer motors)
  • RC3 batch plant control system
Optional features:
  • 4-in-line aggregat bin in place of cross configuration 100 ton, 150 ton or 200 ton in place of 66 ton
  • 530 Bbl. two campartment cement bin in place of single compartment bin
  • 725 Bbl. one or two compartment bin in place of 530 Bbl. single compartment bin
  • Ladder, cage and handrails around top of cement bin (ships seperately)
  • 48" batching belt and 50 horsepower drive
  • Batchers in 10 cubic yards or 12 cubic yards capacity
  • Batched water holding reservoir, with fast-acting, electric-controlled, air operated dump-valve
  • Mixer maintenance platform, complete with expanded metal walkway, rails and toeboards
  • Tilt-mixer nose cone shroud with provisions for attaching a 16" ducting from customer supplied dust collector
